Best applicable for use in hygienic or aseptic pipes and containers or tanks even with very small immersion lengths. It meets increased protection requirements of the temperature sensor regarding physical and chemical effects. Ideally suited to all measuring points that require regular recalibration by simply replacing the insert in closed processes.
Specially designed for use in hygienic and aseptic applications in the Food & Beverages and Life Sciences industries
Pressure range up to 40 bar (580 psi)
For increased protection requirements of the temperature sensor regarding physical and chemical effects
For use in pipes and containers or tanks
Ideally suited to all measuring points that require regular recalibration by simply replacing the insert in closed processes
Fordele
iTHERM QuickNeck – cost and time savings thanks to simple, tool-free recalibration of the insert used
Over 50 hygienic process connections
Global portfolio with metric and imperial versions
International certification: hygiene standards as per 3-A®, EHEDG, ASME BPE, FDA, TSE Certificate of Suitability
This white paper explains how self-calibrating thermometers can be used in hygienic process engineering. It details theory and practice as well as application examples. Learn more!
Chr. Hansen opnåede nemmere temperaturovervågning og kalibrering, hvilke begge er kritiske for UHT-behandlingen af ernæringsoplysningen, vha. iTHERM TM411-temperatursensoren
metric style hygienic/aseptic design (3-A®, EHEDG, ASME BPE, FDA) hygienic process connections iTHERM QuickNeck for easy and cost saving recalibration
Head connection
iTHERM QuickNeck male thread: M24x1,5 G3/8"
Maximum standard immersion length
4.000 mm (157,48")
Max. immersion length on request
Not defined
Process connection
compression fitting weld in adaptor clamp connections acc. to ISO2852 screwed pipe joint acc. to DIN 11851 aseptic screwed pipe joint acc. to DIN 11864-1 metallic sealing system thread acc. to ISO 228 for liquiphant adaptor APV Inline Varivent Ingold SMS 1147 Neumo Biocontrol Tee and elbow thermowells DIN11865
Misura della temperatura e componenti di sistema per i settori
alimentare e
farmaceutico.
PU (udgivelse)
Italiensk version - 01/2020
New version available in English
Misura della temperatura e componenti di sistema per i settori alimentare e farmaceutico. La nuova frontiera dell'igiene: un'offerta complete per applicazioni igieniche e asettiche
